About: Alinx AXAU15 FPGA Development Board with AMD Artix UltraScale+
Alinx AXAU15 FPGA Development Board equipped with the AMD Artix UltraScale+ series device, delivers standout performance with DDR4 SDRAM, QSPI Flash, PCIe, FMC HPC, Gigabit Ethernet. Compatible with a multitude of FMC board (data acquisition, motor control, display camera interfaces, software defined radio), Provide high-speed communication (PCIe).Features:
1 x FMC HPC (37 pairs lvds ios + 8 pairs GTH)
1 x PCIe® Gen4 ×4
1 x Gigabit Ethernet
1 x UART(USB to UART)
2 x 40-pin Expansion Port (40 pin 2.54mm spacing, with 34 IOs, connected to ALINX modules such as binocular cameras, TFT LCD screens, high-speed AD modules, etc.)
1 x MicroSD
1 x 512 Byte EEPROM 24LC04
1 x Temperature sensor LM75
LED (1 x PWR + 1 x DONE + 1 x RXD + 1 x TXD + 2 x LED)
KEY (2 x KEY)
12V single supply
Dimensions: 188 x 106 mm form factor
Model: AXAU15
Alinx AXAU15 FPGA Development Board with AMD Artix UltraScale+
- Brands Alinx
- Product Code:AXAU15
- Availability:In Stock
-
$750.00
