About: AJA Hi5 12G-SDI to HDMI 2.0 Converter

AJA HA5 HDMI 2.0 to 12G-SDI Converter offers single channel transmitters capable of extending HDMI 4K/UltraHD signals over long distances, up to 10km over a single LC or ST Fiber link respectively. These models ship with SFPs installed, and include all functionality of the HA5-12G, with the added benefit of extending audio and video signals further.

Features:

Convert HDMI 2.0b to 4K/UltraHD 60 fps to 12G-SDI with a second mirrored output
Supports up to 60p input at 4:4:4/4:2:2/4:2:0
Supports 12-bit workflows
EDID LFR & HFR Emulation up to UHDp60
Real-timeHDMI HDR Infoframe data reporting
HDR signaling metadata pass-through and optional override
Simple Frame Rate Conversion (FRC) between Fractional and Integer rates
Embedded audio can be selected from the HDMI or Analog audio inputs
Embedded audio pass-through of AC-3 (Dolby Digital) and E-AC-3 (Dolby Digital Plus) compressed audio, including DD+ Atmos (aka DD+ JOC)
Configure via USB port and supplied AJA Mini-Config software
Uses 5-16 VDC power (Universal power supply included)
Five year warranty
